08-03-2017 02:25 PM - edited 08-03-2017 02:26 PM
I've setup a Zone Protection network profile and applied it to our DMZ zone. I changed the default for port scan on the Reconaissance Protection tab to 30 events in 3 seconds. TCP port scan is enabled, and the action is set to block-IP.
I run a test by scanning a host in the DMZ, 10,000 ports in 166 sec. That's a rate of ~ 60 port / sec, and it should have triggered the ZP profile, but didn't.
Do security policies take precedence over ZP, or vice versa?
08-10-2017 08:47 AM
Hi BPry,
Hmm session limit, that should have been a clue... 🙂 Yes I was testing the policy on the DMZ. I'll raise the session count and test again. Thanks again for helping me out, it's very much appreciated.
08-10-2017 09:41 AM
BPry,
This is amazing. Already 4 flood events logged in 15 minutes or so... I'm putting these guys in my EDL by hand, for now. It'll be tricky to be patient enough to build a good baseline.
08-10-2017 09:56 AM
If you're adding all of them to an EDL you have a good reason to upgrade to PAN-OS 8. With the new features in the llg forwarding profile settings you could easy automate what you're now doing manually and the EDL.
But this is a point where you have to be careful, because floods from spoofed IP addresses, could let you block IPs from legimate addresses.
08-10-2017 10:03 AM
Hi vsys_remo,
Good to know. Unfortunately upgrading to 8.x is not in the cards for now.
08-10-2017 01:43 PM
I would look into incorporating MineMeld into the mix then. Doing it manually will get kind of boring, so the more you can automate the process the better. Flood IPs I generally specify that they need to be introduced x amount of times before they'll be blocked.
08-10-2017 02:26 PM
Hi BPry,
I hear you. Actually I've already setup a syslog miner node on MineMeld. The node is getting the logs just fine, but I'm having some trouble figuring out the correct syntax for the rules.
I have a separate thread going on here:
Would you be willing to share what rules you are using on MineMeld, since you obviously have already figured this out. 🙂
