PING from Firewall GUI

Hi All,



I have a basic doubt.

Isit possible to ping from firewall GUI ?

If not from Panaroma CLI, isit possible to connect firwall ( to test the ping from firewall to host )



Reason : To check the network latency from fireawall.



Thanks

KM

Highlighted
L7 Applicator

Re: PING from Firewall GUI

hi @karthik2019



No, this can not be done from the GUI

you can from the CLI from 2 different 'planes'



>ping host x.x.x.x

will ping from the management interface

>ping source y.y.y.y host x.x.x.x

will ping from the dataplane interface that owns ip y.y.y.y



reaper - PANgurus.com
I drink and I know things
Highlighted
L0 Member

Re: PING from Firewall GUI

Thanks for your reply ..

I did tried it .



Panorama>ping source ( firewall management ip ) host ( host ip )



I am getting below error :



bind: Cannot assign requested address



Thanks

KM

Highlighted
L7 Applicator

Re: PING from Firewall GUI

The ping command only works from the local device, panorama does not have dataplane interfaces so you can't add source from panorama either

To be able to run the ping from a firewall, you need to connect to the firewalls' CLI

reaper - PANgurus.com
I drink and I know things
Highlighted

Re: PING from Firewall GUI

Thanks for your reply, much appreciated.



yes i get it , that is my catch .. I have issue login firewall CLI so, trying all steps to use panorama CLI to get some ICMP reply for firewall.



Thanks again for confirmatiom.



KM



Highlighted
L1 Bithead

Re: PING from Firewall GUI

Had same error- "bind: Cannot assign requested address" on firewall when sourcing ping from ethernet 1/5 (not Panorama).  Found that after we had done a load saved config snapshot to restore a config, one of the physical interfaces had the "untagged subinterface" checkbox checked.  We undid this checkbox and everything was back to normal.  Hope this can help someone else.
