My Global protect VPN certificate is expiring soon. How to renew it

L2 Linker

My Global protect VPN certificate is expiring soon. How to renew the certificate. System engineer provider me certificate in .p12 format. This is my first time to do cert renewal. Please guide me. Thank you.

2 accepted solutions

Accepted Solutions

I assume you mean the portal/gateway server certificate is expiring.  You should be able to go to Device > Certificates > Import.  From there you can select "Encrypted Private Key and Certificate (PCKS12) from the File Format drop-down menu.  You'll need the password used by the sysadmin to encrypt the certificate as well.


Once you've imported the new certificate, you'll want to go to Device > SSL/TLS Service Profile, open whichever SSL/TLS profile is used on your GlobalProtect gateway/portal, and select your new cert in the certificate drop-down.






View solution in original post

Personally, I would wait to revoke the other certificate until you have the new certificate imported and tested, just in case you have to roll back your changes, but that's just my opinion.  If you go this route, you'll need to give them different names.  You can rename the old one, or give the new one a different name like MyCompanyName-2020-2021 for the dates the certificate is valid.  Whatever you want, just so they are different.

View solution in original post

8 REPLIES 8

L2 Linker

@OwenFuller can you please help me on this 🙂

I assume you mean the portal/gateway server certificate is expiring.  You should be able to go to Device > Certificates > Import.  From there you can select "Encrypted Private Key and Certificate (PCKS12) from the File Format drop-down menu.  You'll need the password used by the sysadmin to encrypt the certificate as well.


Once you've imported the new certificate, you'll want to go to Device > SSL/TLS Service Profile, open whichever SSL/TLS profile is used on your GlobalProtect gateway/portal, and select your new cert in the certificate drop-down.






Yes, I have password for cert. Thanks Owen. You are so helpful.

@OwenFuller My existing cert name is 'MyCompanyName'. I want to use same name 'MyCompanyName' for new cert, so do I need to revoke  old 'MyCompanyName' cert first and then import the new cert with same name? I have scheduled maintenance window.

Personally, I would wait to revoke the other certificate until you have the new certificate imported and tested, just in case you have to roll back your changes, but that's just my opinion.  If you go this route, you'll need to give them different names.  You can rename the old one, or give the new one a different name like MyCompanyName-2020-2021 for the dates the certificate is valid.  Whatever you want, just so they are different.

I agree with you. Thanks a lot.

Hi OwenFuller,



I'm also the first time to renew our GP VPN device certificates. But my certificates just expired today.

And I checked our old device certificates, it doesn't have the "CA".

When I renew it, do I need to import certificates ".pem" file or "pkcs12"? I don't want to change any current VPN configuration.

I have totally no idea how to do it. Thanks a lot!
Screen Shot 2022-02-19 at 11.33.24 PM.png

The solution worked for me thanks to the community and the members for the solution.
