My Global protect VPN certificate is expiring soon. How to renew it

Reply
Highlighted
L1 Bithead

My Global protect VPN certificate is expiring soon. How to renew it

My Global protect VPN certificate is expiring soon. How to renew the certificate. System engineer provider me certificate in .p12 format. This is my first time to do cert renewal. Please guide me. Thank you.

Tags (1)

Accepted Solutions
Highlighted
L4 Transporter

Re: My Global protect VPN certificate is expiring soon. How to renew it

I assume you mean the portal/gateway server certificate is expiring.  You should be able to go to Device > Certificates > Import.  From there you can select "Encrypted Private Key and Certificate (PCKS12) from the File Format drop-down menu.  You'll need the password used by the sysadmin to encrypt the certificate as well.


Once you've imported the new certificate, you'll want to go to Device > SSL/TLS Service Profile, open whichever SSL/TLS profile is used on your GlobalProtect gateway/portal, and select your new cert in the certificate drop-down.






View solution in original post

Highlighted
L4 Transporter

Re: My Global protect VPN certificate is expiring soon. How to renew it

Personally, I would wait to revoke the other certificate until you have the new certificate imported and tested, just in case you have to roll back your changes, but that's just my opinion.  If you go this route, you'll need to give them different names.  You can rename the old one, or give the new one a different name like MyCompanyName-2020-2021 for the dates the certificate is valid.  Whatever you want, just so they are different.

View solution in original post


All Replies
Highlighted
L1 Bithead

Re: My Global protect VPN certificate is expiring soon. How to renew it

@OwenFuller can you please help me on this

Highlighted
L4 Transporter

Re: My Global protect VPN certificate is expiring soon. How to renew it

I assume you mean the portal/gateway server certificate is expiring.  You should be able to go to Device > Certificates > Import.  From there you can select "Encrypted Private Key and Certificate (PCKS12) from the File Format drop-down menu.  You'll need the password used by the sysadmin to encrypt the certificate as well.


Once you've imported the new certificate, you'll want to go to Device > SSL/TLS Service Profile, open whichever SSL/TLS profile is used on your GlobalProtect gateway/portal, and select your new cert in the certificate drop-down.






View solution in original post

Highlighted
L1 Bithead

Re: My Global protect VPN certificate is expiring soon. How to renew it

Yes, I have password for cert. Thanks Owen. You are so helpful.

Highlighted
L1 Bithead

Re: My Global protect VPN certificate is expiring soon. How to renew it

@OwenFuller My existing cert name is 'MyCompanyName'. I want to use same name 'MyCompanyName' for new cert, so do I need to revoke  old 'MyCompanyName' cert first and then import the new cert with same name? I have scheduled maintenance window.

Highlighted
L4 Transporter

Re: My Global protect VPN certificate is expiring soon. How to renew it

Personally, I would wait to revoke the other certificate until you have the new certificate imported and tested, just in case you have to roll back your changes, but that's just my opinion.  If you go this route, you'll need to give them different names.  You can rename the old one, or give the new one a different name like MyCompanyName-2020-2021 for the dates the certificate is valid.  Whatever you want, just so they are different.

View solution in original post

Highlighted
L1 Bithead

Re: My Global protect VPN certificate is expiring soon. How to renew it

I agree with you. Thanks a lot.
